Wide Web Slitting

Wide Web Slitting Capabilities

• Out of the eleven (11) wide web slitters owned by Pro Tapes®, six (6) are fully automatic machines with a vast array of features, including wrapping and packaging
• Universal tooling enables Pro® to automatically produce roll widths greater than 75mm
• Inline automatic closed core shrink wrapping & open core sleeve wrapping
• In-line PSA roll labeling system
• In-line automatic case assembly & auto packaging
• In-line open & close core wrapping
• Slitting methods: razor, score and shear set up capabilities
• Cores sizes: 1”, 1 ½”, 3”, up to 6” core I.D.
• Finished rolls up to 800mm O.D. with automatic off load
• Wide Web Laminating: 6 units, up to 1800mm wide (70.87”)
• Rewind methods: lock core, slip core, traditional differential and pneumatic differential (each roll is independent) core
• Profile controls: minimum gap, center surface, taper tension, and lay on rollers
• Substrates: Non-PSA, PSA Single-faced, PSA Double-coated, Paper, Cloth, Films, Specialty, Butyl Rubber, Foams, Vinyl, PVC, etc.
• Tabbing: Standard paper tabs for start-up and double-coated tabs for non-PSA products or linered products.
• Capable to convert any type of PSA or non-PSA material up to 5mm in thickness
• Computerized winding controls with programmable roll profile, adjusting torque and speed
• Maximum rewind diameter up to 800mm
• Automatic blade positioning with accuracy of +/_ 0.1mm
• Laser core positioning
• Storable production recipes for repeatability
